Engineering & Design for Ultra-High Vacuum
UHV Store provides specialised engineering services for scientific instrumentation, surface science, and ultra-high vacuum (UHV) applications.
Our expertise includes the conceptual design and development of experimental end stations at synchrotron and free-electron laser facilities, laboratory vacuum systems, and precision mechanical components for sample preparation, transfer, positioning, and manipulation.
We support research institutions and industrial customers throughout the development process, from initial design concepts to manufacturing-ready solutions.
3D CAD Design with CATIA V5
Our mechanical engineering and design work is based on CATIA V5, a professional CAD platform widely used for complex mechanical assemblies and precision engineering.
Services include 3D modelling, assembly design, technical drawings, component optimisation, and design-for-manufacturing support.
Particular attention is given to vacuum compatibility, material selection, mechanical tolerances, thermal behaviour, and integration into existing experimental equipment.
Precision Manufacturing & Swiss Supplier Network
UHV Store collaborates with an established Swiss supplier network to manufacture precision mechanical components, prototypes, and production parts.
Available manufacturing capabilities include CNC milling and turning for complex mechanical components.
Our manufacturing network includes a Mori-Seiki SH40 horizontal 4-axis milling centre, equipped with a six-pallet system and machining travels of X 560 mm, Y 510 mm, and Z 510 mm.
This setup supports efficient production of precision-machined components and medium-sized to larger production batches.
Custom UHV Components & Scientific Instruments
Custom engineering projects may involve vacuum chambers, mechanical assemblies, sample handling components, manipulators, and specialised research equipment.
We support customers with mechanical design, material selection, manufacturing feasibility, prototype development, and coordination with suitable production partners.
For standard vacuum components, explore our CF Flanges & Components, Motion & Manipulation, and UHV Sample Holders & Receivers.
Engineering Support & Consultation
Professional engineering assistance is available through our Technical Engineering & Design Support service.
Each unit corresponds to one hour of engineering work and can be used for technical consultation, CAD design, feasibility assessments, and development support.
For larger projects, please contact UHV Store with your drawings, specifications, and technical requirements to discuss a suitable engineering and manufacturing solution.
