Drawer Style Receivers for Flag Style Sample Holder Plates
Drawer Style Receivers for Flag Style Sample Holder Plates
Couldn't load pickup availability
The standard receptacle version for Flag style sample plates is manufactured from one block. The sample plate is secured by two ruby spheres which are pressed against the rear of the sample plate by a leaf spring - the leaf spring is held in position by itself. The receptacle can be manufactured from a variety of materials.
Low temperature version
Leaf springs press for better thermal contact the sample plate down onto the face of the sample drawer via two Ruby spheres. The leaf spring is held in position by two screws.
With it's melting point of 2900K, Molybdenum is an excellent choice of material for high temperature applications. At the other end, the high themal conductivity and the low expansion coefficient also make it an ideal choice for experiments at very low temperatures below 4K.
For use above 1000K, it is strongly recommended not to use Molybdenum sample plates. Very likely, the sample plates will be welded to the receiver. Choose tungsten, Tantalum or a ceramic material instead to avoid sticking.
Sample drawer made of oxygen-free High Purity Copper (OFHC, Cu-OFE) with Gold plating and high quality of surfaces is an excellent choice of material for cryogenic only applications and ensure good thermal cryogenic contact to the sample plate.
- fully UHV compatible
- ruby spheres for sample plate stability









We encountered one issue: The seats for the screws were not compatible with the sample receiver with contacts. So we had to make new threads in the conterpiece. Regards Gerd Schönhense
Dear Gerd,
Thank you very much for your valuable feedback! I have discussed this issue with Ferrovac, and we confirmed that the mounting hole patterns of the RECOM and RECOMEC13 series are indeed incompatible. Surprisingly, this has never been reported before. We will take your feedback into account in future design revisions to improve compatibility between the components.
I apologise for the additional machining work required and appreciate you bringing this to our attention!
Best regards,
David
quick delivery, excellent quality
